Fit your shutters yourself, step by step.
No experience needed. Each guide is written for DIYers of every level, whichever line you chose.
How to install LuxFit
LuxFit shutters install without tools using a clip-in system. No screws, no drilling: just clean mounting inside your uPVC window frame.
Tools you'll need
- Credit cardas a spacer
- Step stoolif needed
- Clean clothto wipe surfaces
- 1
Insert the brackets
Use a credit card to find the correct bracket depth.
Slide each bracket gently into the gasket seal, starting with the bottom corners, then the top. - 2
Clip in the shutters
Align the shutter frame with the bottom brackets and push down to clip in.
Press the top of the frame into the upper brackets until it clicks securely. - 3
Final checks
Make sure the shutter is fully engaged in all brackets.
Open and close the louvres to test that they move freely and clear the window.
Your progress
- 1Insert the brackets
- 2Clip in the shutters
- 3Final checks
Your LuxFit shutters are installed.
Open and close the panels a few times, and enjoy the light.
